Purpose of Providing The Chair Bar

• In the construction field some different purposes for using the chair bar in the foundation and slab.
• The basically primary purpose for using it is to maintain the cover or gap between the bottom and top bar.
• The chair bar gives vertical support between the top and bottom bar.
• The purpose of using the chair bar for the tension Zone.
• The diameter of the chair bar must be 12mm or more than 12mm.
• The purpose of using the chair bar for Reduced bends between the bottom and top bar.

Main Parts of The Chair Bar

The chair bar has the three parts

Chair Bar Head

Chair Bar Height

Chair Bar Leg

1- Chair Bar Head

The head of the chair bar is the main top portion of the bar is called Chair bar Head. The location of the chair bar head is below the top bar of the foundation or slab. The length of the chair bar head is equal to 2-time spacing + 2 multiplied by 50. The value of 50 is constant.

Length of the Chair Bar Head = 2 x spacing +2 x 50

2- Chair Bar Height

The chair bar height is the vertical portion of the chair bar is called chair bar height. The height of the chair bar is important to calculate.

Chair Bar Height = Total Height -Top and bottom concrete cover -Top long and short bar – bottom long bar

3- Chair Bar Leg

The Chair bar leg is the bottom part of the chair bar is called chair bar leg. The location of  This portion of the bar is at the top of the bottom long bar. The length of the chair bar leg is 2 times spacing + 50. The value of 50 is constant.

length of the chair bar leg = 2 x spacing +50

Calculate The Cutting length For Chair Bar

Given Data For Example

Depth of the foundation = 1200mm =1.200m

Diameter of the short bar =16mm

Diameter of the long bar =16mm

spacing between both bar = 150mm

Diameter of the chair bar = 12mm

Concrete Cover for all sides(C.C) = 50mm

Now Solutions

Calculate Load And Design Calculation For Column Beam Wall And Slab

Important Principles For Design The Column

Measurements Of Workability For Fresh Concrete

Calculate the Length of the Chair bar

Chair bar head Length

Chair bar head Lenght  = 2 x spacing +2 x 50      (The value of 50 is constant)

Chair bar head Lenght = 2 x 150 +2 x 50 = 400mm=0.400m

Chair bar Leg Length

Chair bar Leg Lenght  = 2 x spacing  + 50   (The value of 50 is constant)

Chair bar Leg Lenght  = 2 x 150 + 50 = 350mm = 0.350m

Two legs of the chair bar

The total length of the chair bar leg = 350 x 2 = 700mm = 0.700m

Length of chair bar height

Length of chair bar height = Total Depth of foundation -top and bottom C.C – top long and short bar – long bottom bar

Length of chair bar height = 1200 – 50 -50 -2(16) – 16

Length of chair bar height = 1200 -100-32-16 = 1052mm=1.052m

Two sides of the chair heights

Two sides of the chair height = 1052 x 2 =2104mm = 2.104m

Now Calculate the Cutting length of the chair bar

Total Cutting length of the chair bar = 2 x chair bar leg + 2 chair bar height +chair bar head -4 x 90ºbends        (90ºbends =2d = 2 x12 = 24)

Total Cutting length of the chair bar = 2 x350 + 2 x 1052 + 400 – 4 x24

Total Cutting length of the chair bar = 700 + 2104 + 400 – 86= 3118mm=3.118m
